WORLDSEMI WS2815B series 5050RGB Phantom Color LED Integrated Bead DC12V Single Point Single Control Built-in IC
WORLDSEMI WS2815B series 5050RGB Phantom Color LED Integrated Bead DC12V Single Point Single Control Built-in IC
Brand:WORLDSEMI
Model No: WS2815B-RGB-5050 W52815B-V1 WS2815B-RGBW-4P
Size:5050
Imported : No
Item No : NA
Power : 0.3 (W)
Forward Voltage : 12(V)
Rated current: 12 (A)
Phosphor Brand : NA
Bracket Material: Copper
Color tolerance : NA (SDCM)
Temperature coefficient of voltage : NA (mV/C)
Product Features:
- The control circuitry is integrated with the RGB chip in a single 5050-packaged component, constituting a complete externally controlled image cable point.
- The 12V power supply voltage effectively reduces the working current of the whole pixel point, reduces the voltage drop of the circuit board, and maximally ensures that the pixel point achieves good light-mixing consistency when it is transmitted over a long distance.
- Built-in signal shaping circuit, any pixel point receives the signal after waveform shaping and then output, to ensure that the line waveform distortion will not accumulate.
- The three primary colors of each pixel point can achieve 256 levels of brightness display, completing the full true color display of 16777216 colors.
- Port scanning frequency 2KHz.
- Serial cascade interface, capable of receiving and decoding data over a single signal line.
- Continuous transmission of broken points, an additional way to add a signal line, to achieve dual signal transmission, in the case of damage to a single pixel point, does not affect the overall display effect
- No additional circuitry is required when the transmission distance between any two points does not exceed 5 meters.
- When the refresh rate is 30 fps, the number of cascades is not less than 1024 points.
- Data can be sent at speeds up to 800Kbps.
- The color of the light is highly consistent and cost effective.
The industry's first 12V single-point single-control phantom color light beads at the same time with a breakpoint continuous transmission function of the phantom color LEDs
Rich and vivid colors, high visibility, full-color light bar 10 meters without color differences, 12mA constant current output, internal capacitors, without any other peripheral electronic components to assist
WORLDSEMI
SKU:
View full details![WORLDSEMI WS2815B series 5050RGB Phantom Color LED Integrated Bead DC12V Single Point Single Control Built-in IC](http://worldsemi.myshopify.com/cdn/shop/files/WS2815A-5054.jpg?v=1723260739&width=1445)
![WORLDSEMI WS2815B series 5050RGB Phantom Color LED Integrated Bead DC12V Single Point Single Control Built-in IC](http://worldsemi.myshopify.com/cdn/shop/files/15B-5050.jpg?v=1721720445&width=1445)
![WORLDSEMI WS2815B series 5050RGB Phantom Color LED Integrated Bead DC12V Single Point Single Control Built-in IC](http://worldsemi.myshopify.com/cdn/shop/files/15B-RGBW-5050.jpg?v=1721721519&width=1445)
![WORLDSEMI WS2815B series 5050RGB Phantom Color LED Integrated Bead DC12V Single Point Single Control Built-in IC](http://worldsemi.myshopify.com/cdn/shop/files/15B-RGBW-4P.jpg?v=1721720394&width=1445)
![WORLDSEMI WS2815B series 5050RGB Phantom Color LED Integrated Bead DC12V Single Point Single Control Built-in IC](http://worldsemi.myshopify.com/cdn/shop/files/15B-5050_a049ba14-d80b-42e1-8560-a70e2840cbe5.jpg?v=1723255846&width=1445)
![WORLDSEMI WS2815B series 5050RGB Phantom Color LED Integrated Bead DC12V Single Point Single Control Built-in IC](http://worldsemi.myshopify.com/cdn/shop/files/2815E-5050.jpg?v=1723255864&width=1445)
![WORLDSEMI WS2815B series 5050RGB Phantom Color LED Integrated Bead DC12V Single Point Single Control Built-in IC](http://worldsemi.myshopify.com/cdn/shop/files/2815C-2121.jpg?v=1723261672&width=1445)
![WORLDSEMI WS2815B series 5050RGB Phantom Color LED Integrated Bead DC12V Single Point Single Control Built-in IC](http://worldsemi.myshopify.com/cdn/shop/files/WS2815C-3535.jpg?v=1723451459&width=1445)
